Table 15-4 Class: HPSA_StorageVolume (CIM_StorageVolume)
Property name
Property implementation
CIM_ManagedElement
ElementName
Logical drive number with raid description (for
example, Logical Volume 1 (RAID 1+0))
CIM_ManagedSystemElement
Name
VPD Pg83 identifier for the volume.
OperationalStatus[0, 1]
Volume status. DMTF defined value is populated in
index[0] and extended status is poplulated in index[1]
per HP Smart Array Profile.
 In a multipath scenario, if one or more path to
volume fails, then OperationalStatus is degraded.
 If all the path to volume fails, then
OperationalStatus resuts in an error.
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_LogicalDevice
CreationClassName
HPSA_StorageVolume
DeviceID
Opaque Key
SystemCreationClassName
HPSA_ArraySystem
SystemName
HPSA_ArraySystem.Name
CIM_StorageExtent
ConsumableBlocks
0
BlockSize
Block Size in bytes
DataRedundancy
 1 (RAID 0, RAID 5, RAID 6, Raid 50, Raid 60)
 2 (RAID 1+0, RAID 1, RAID 1 (ADM), RAID 1+0
(ADM))
DeltaReservation
0
ExtentStatus[0]
This indicates extended status for the volume.
 2 (None)
 11 (Rebuild—Volume is currently rebuilding data)
IsBasedOnUnderlyingRedundancy
False
NoSinglePointOfFailure
 True—RAID 1 or above
 False—RAID 0
NumberOfBlocks
Total Number of blocks on the volume
