HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 15-2 Class: HPSA_ArraySystem (CIM_ComputerSystem)
Property name
Property implementation
CIM_ManagedElement
ElementName
Controller/Storage System name and location
Examples:
 Smart Array in Slot 3, for internal
 MSA500 in SystemCab03, for external
CIM_ManagedSystemElement
Name
 Controller Serial Number
 EMBEDDED—Reported if there is no Serial Number
for device is local (embedded on motherboard).
 PCISLOTSlot number—Reported if there is no Serial
Number for device is local (PCI occupies a slot).
OperationalStatus[0]
Overall status of the Array System and attached
devices. This is calculated per the algorithm desciribed
in the HP Smart Array Profile.
 0 (Unknown)
 2 (OK)
 3 (Degraded)
 6 (Error)
StatusDescriptions[0]
More info for OperationalStatus result. This provides a
short decription to identify who is contributing to non-
OK status.
Examples:
 Logical Drive Failure
 Physical Drive Degraded/Failed
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_System
CreationClassName
HPSA_ArraySystem
NameFormat
Other
IdentifyingDescriptions
Other Vendor Specific Name
OtherIdentifyingInfo
 Controller Serial Number
 EMBEDDED—Reported if there is no local Serial
Number for device (embedded on motherboard)
 PCISLOT Slot number—Reported if there is no local
Serial Number for device (PCI occupies a slot)
