HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 13-17 Class: HP_EthernetGroupHostedCollection
Property name
Property implementation
CIM_Dependency
Key:Antecedent
ref:HP_ComputerSystem
Key:Dependent
ref:HP_EthernetCollection
CIM_HostedDependency
CIM_HostedCollection
HP_EthernetGroupHostedCollection
13-3-17 CIM_IPProtocolEndpoint
The following table lists the property implementation for CIM_IPProtocolEndpoint. The Windows®
implementation class is HP_WinEthIPProtocolEndpoint.
Table 13-18 Class: CIM_IPProtocolEndpoint
Property name
Property implementation
CIM_ManagedElement
Caption
Same as associated LAN endpoint
Description
Same as associated LAN endpoint
ElementName
Same a caption
CIM_ManagedSystemElement
Key:Name
System GUID for the associated Ethernet LAN
Endpoint, concatenated with the IP Address.
HealthState
Same as associated LAN endpoint
OperationalStatus[0]
Same as associated LAN endpoint
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
RequestedState
12 (Not Applicable)
CIM_ServiceAccessPoint
Key:CreationClassName
HP_WinEthIPProtocolEndpoint
Key:SystemCreationClassName
HP_WinComputerSystem
Key:SystemName
Name of Server
CIM_ProtocolEndpoint
ProtocollFType
4096 (IPv4)
