13-3-10 HP_IPBindsToEthernetLANEndpoint
HP_IPBindsToEthernetLANEndpoint associate IP Protocol Endpoints to LAN Endpoints. The Windows®
implementation class is HP_WinIPBindsToEthLANEndpoint.
Table 13-11 Class: HP_IPBindsToEthernetLANEndpoint
Property name
Property implementation
CIM_SAPSAPDependency
CIM_BindsTo
CIM_BindsToLANEndpoint
FrameType
1 (Ethernet)
HP_IPBindsToEthernetLANEndpoint
Key:Antecedent
ref:HP_EthernetLANEndpoint
Key:Dependent
ref:CIM_IPProtocolEndpoint
13-3-11 HP_EthernetStatistics
The following table lists the property implementation for HP_EthernetPortStatistics. The Windows®
implementation class is HP_WinEthernetPortStatistics.
Table 13-12 Class: HP_EthernetStatistics
Property name
Property implementation
CIM_ManagedElement
Caption
 For Ethernet Teams, same as associated
HP_WinEthRedundancySet.Caption
 For Ethernet Ports, same as associated
HP_WinEthernetPort.Caption
Description
Local Area Connection #
ElementName
Same as Caption
CIM_StatisticalData
Key:InstanceId
System GUID of the associated Ethernet Port or LAN
Endpoint
SampleInterval
0
StatisticTime
Time of current statistics
CIM_NetworkPortStatistics
BytesReceived
Total number of bytes received
BytesTransmitted
Total number of bytes transmitted
PacketsReceived
Total number of packets received
PacketsTransmitted
Total number of packets transmitted
