11 Platform Watchdog
11-1 Overview
This provider supports the Platform Watchdog on ProLiant servers.
The following table details the profiles implemented and files installed by this provider.
Table 11-1 Overview
Implemented Profiles
 DMTF Platform Watchdog Profile (DSP1040)
Provider Installation Files
 HPWmiSensor.dll
 HPWmiSensor.mof
11-2 Use cases
For use cases, see the DMTF Platform Watchdog Profile.
11-3 Class implementations
The following classes describe the Watchdog implementation.
11-3-1 HP_WinPlatformWatchdogService
HP_WinPlatformWatchdogService implements the class CIM_PlatformWatchdogService to model
Automatic Server Recovery (ASR) functionality of ProLiant servers. The following properties are
implemented.
Table 11-2 Class: HP_WinPlatformWatchdogService
Property name
Property implementation
CIM_ManagedElement
Caption
Automatic Server Recovery (ASR)
Description
Automatic Server Recovery (ASR)
ElementName
Automatic Server Recovery (ASR)
CIM_ManagedSystemElement
HealthState
 5 (OK), when OperationalStatus[0]=2 (OK)
 20 (Major Failure), when OperationalStatus[0]=6
(Error)
Name
Automatic Server Recovery (ASR)
