HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 8-9 Class: HP_SystemPCIDevice
Property name
Property implementation
PartComponent
References HP_PCIDevice
8-3-9 HP_Location
HP_Location is used to model PCI slot locations on ProLiant Servers. The Windows®-specfic
implementation class is HP_PCISlotLocation.
Table 8-10 Class: HP_Location
Property name
Property implementation
CIM_ManagedElement
Caption
PCI slot n, where n represents the PCI slot position
printed on the system labeling.
Description
The location of PCI slot n. Please refer to PCI slot
position n printed on the system.
n represents the PCI slot position printed on the system
labeling.
ElementName
PCI slot n, where n represents the PCI slot position
printed on the system labeling.
CIM_Location
Name
Unique identifier for this PCI slot location instance
PhysicalPosition
n, where n represents the PCI slot position printed on
the system.
HP_Location
ElementLocationTag
PCI slot n, where n represents the PCI slot position
printed on the system.
ElementLocationTagDesc
0 (HoodTag)
8-3-10 HP_ElementLocation
HP_ElementLocation is used to represent an association between CIM_Location and
CIM_ManagedElement. The Windows®-specfic implementation class is HP_PCISlotElementLocation.
Table 8-11 Class: HP_ElementLocation
Property name
Property implementation
Element
References CIM_ManagedElement
PhysicalLocation
References CIM_Location
