7-4-18 HP_MemoryBoardSlotLocation
The class HP_MemoryBoardSlotLocation extends the HP_Location class and represents memory board
slot locations on ProLiant Servers. There is an instance of this class for each memory board slot in the
system, whether or not the slot is occupied.
Table 7-22 Class: HP_MemoryBoardSlotLocation
Properties
Property implementation
CIM_ManagedElement
Caption
Memory Board Slot Location x, where x is the
board/cartridge number where the memory board slot
is located.
Memory on Processor Board Slot Location x, where x is
the processor board/cartridge number where the
memory board slot is located.
Description
Memory Board Slot Location x, where x is the
board/cartridge number where the memory board slot
is located.
Memory on Processor Board Slot Location x, where x is
the processor board/cartridge number where the
memory board slot is located.
ElementName
Memory Board Slot Location x, where x is the
board/cartridge number where the memory board slot
is located.
Memory on Processor Board Slot Location x, where x is
the processor board/cartridge number where the
memory board slot is located.
CIM_Location
Name
HPQ:HP_MemoryBoardSlotLocation:x, where x is the
board/cartridge number where the memory board slot
is located
PhysicalPosition
x, where x is the board/cartridge number where the
memory board slot is located.
HP_Location
ElementLocationTag
x, where x is the board/cartridge number where the
memory board slot is located.
ElementLocationTagDesc
9 (Memory Board) /13 (Processor Board)
LocationInformation
LocationInformation[0] text: x, where x is the
board/cartridge number
LocationInfoDesc
LocationInfoDesc[0] = 5 (Memory Board) /
LocationInfoDesc[0] = 15 (Processor Board), indicates
that the first element of the LocationInformation array
contains the board/cartridge number
HP_MemoryBoardSlotLocation
