HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 7-21 Class: HP_MemoryModuleSlotLocation
Property name
Property implementation
ElementName
Memory Module Socket Location y on Board x, where:
 x is the board/cartridge number where the memory
module slot is located
 y is the memory socket number where the memory
module slot is located
Memory Module Socket Location y on Processor Board
x, where:
 x is the processor board/cartridge number where
the memory module slot is located
 y is the memory socket number where the memory
module slot is located
CIM_Location
Name
HPQ:HP_MemoryModuleSlotLocation:x-y, where:
 x is the board/cartridge number where the memory
module slot is located
 y is the memory socket number where the memory
module slot is located
PhysicalPosition
x-y, where:
 x is the board/cartridge number where the memory
module slot is located
 y is the memory socket number where the memory
module slot is located
HP_Location
ElementLocationTag
x-y, where:
 x is the board/cartridge number where the memory
module slot is located
 y is the memory socket number where the memory
module slot is located
ElementLocationTagDesc
8 (Memory Module)
LocationInformation
LocationInformation[0] text: y, where y is the memory
socket number
LocationInformation[1] text: x, where x is the
board/cartridge number
LocationInfoDesc
LocationInfoDesc[0] = 4 (Socket), indicates that the first
element of the LocationInformation array contains the
socket number
LocationInfoDesc[1] = 5 (Memory Board) / 15
(Processor Board), indicates that the second element of
the LocationInformation array contains the
board/cartridge number
HP_MemoryModuleSlotLocation
