HP Confidential

Table 7-8 Class: HP_MemoryRedundancySet

Property name

Property implementation

CurrentConfigurations

The current operating mode of the Advanced Memory

Protection system.

 Advanced ECC, when the system is operating in

Advanced ECC mode

 RAID-XOR, when the system is operating in RAID

(XOR) mode

 Mirroring, when the system is operating in

Mirrored mode

 Single Board Mirroring, when the system is

operating in Single Board Mirrored mode

 Dual Board Mirroring, when the system is

operating in Dual Board Mirrored mode

 Mirrored Intrasocket, when the mirroring is with a

DIMM in the same socket.

 Mirrored Intersocket, when the mirroring is with a

DIMM in different socket.

 Online Spare, when the system is operating in

Online Spare mode

 Online Spare Channel, when the system is

operating in Online Spare Channel mode

 Online Spare Rank, when the system is operating

in Online Spare Rank mode

 Lockstep, when the system is operating in Lockstep

mode

TargetConfigurations

The RBSU selected mode of the Advanced Memory

Protection system.

 Advanced ECC, when the system is configured for

Advanced ECC mode

 RAID-XOR, when the system is configured for RAID

(XOR) mode

 Mirrored, when the system is configured for
