HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 7-8 Class: HP_MemoryRedundancySet
Property name
Property implementation
Caption
Memory Redundancy Set
Description
Memory Redundancy Set for Advanced Memory
Protection
ElementName
Memory Redundancy Set
CIM_SystemSpecificCollection
InstanceID
HPQ:HP_MemoryRedundancySet:001
CIM_RedundancySet
TypeOfSet
The type of redundancy currently in operation for the
Advanced Memory Protection system..
TypeOfSet contains the current type of redundancy:
 1 (Other), when the system is operating in
Advanced ECC mode or Lockstep mode
 2 (N+1), when the system is operating in RAID
(XOR) mode
 3 (Load Balanced), when the system is operating in
Mirrored mode
 4 (Sparing), when the system is operating in Online
Spare mode
OtherTypeOfSet
OtherTypeOfSet contains the type of redundancy when
the corresponding property TypeOfSet contains 1
(Other). In this case, the property will contain the value
Advanced ECC or Lockstep, otherwise the property is
not populated.
LoadBalanceAlgorithm
2 (No Load Balancing)
RedundancyStatus
The current memory redundancy status as follows:
 2 (Fully Redundant)—System is operating properly
in the Advanced Memory Protection mode given in
the CurrentConfigurations property.
 3 (Degraded Redundancy)— System is operating in
the CurrentConfigurations mode but memory
module(s) have correctable errors exceeding the
condition for pre-failure warranty.
○
HP_MemoryRedundancySet
OperatingSpeed
The current operating speed of the advanced memory
protection subsystem in MHz
AvailableMemory
The size of the memory as seen by the operating
system in MB
TotalMemory
Total size of memory as seen by the operating system
and memory used for advanced memory protection
configurations in MB
