HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 7-6 Class: HP_MemoryBoard
Property name
Property implementation
HealthState
Enumerator indicating the memory board health state:
 0 (Unknown), when OperationalStatus[0] = 0
(Unknown)
 5 (OK), when OperationalStatus[0] = 2 (OK)
 10 (Degraded/Warning), when
OperationalStatus[0] = 3 (Degraded)
Name
Physical Memory Board x, where x is the
board/cartridge number where the memory board is
located.
Physical Memory for Processor Board x, where x is the
processor board/cartridge number where the memory
board is located.
CIM_PhysicalElement
CreationClassName
HP_MemoryBoard
Tag
HPQ:HP_MemoryBoard:x, where x is the
board/cartridge number.
Description
Physical Memory Board x, where x is the
board/cartridge number where the memory board is
located.
Physical Memory for Processor Board x, where x is the
processor board/cartridge number where the memory
board is located.
ElementName
Physical Memory Board x, where x is the
board/cartridge number where the memory board is
located.
Physical Memory for Processor Board x, where x is the
processor board/cartridge number where the memory
board is located.
CIM_PhysicalPackage
RemovalConditions
Removal conditions of the memory board:
 When the memory board is the system board:
○ 2 (Not applicable)
 When the memory board is not the system board:
○ 3 (Removable when off)
○ 4 (Removable when on or off)
PackageType
9 (Module/Card)
VendorCompatibilityStrings
HPQ:HP_MemoryBoard
CIM_Card
HostingBoard
 True—Indicates if this is a baseboard in the
computer system chassis
 False—Memory board not on the baseboard
