HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 7-4 Class: HP_MemoryModule
Property name
Property implementation
Spd
An array that contains raw Serial Presence Detect
information for the memory module. Each array
element contains a byte of the Spd.
This property is conditional; it is populated if the data
is available.
Type
A numeric value idicating the presense of a HP Smart
Memory module.
0 (Unknown)
1 (Other)
2 (HP DIMM)
MinimumVoltage
This value specifies the minimum voltage needed
for the memory module to operate in millivolts. If
this value cannot be determined, then a value of
0 will be returned.
Ranks
The number of physical ranks on the module
Technology
Technology type of the memory module
Table 7-5 Memory Module Status
Condition
OperationalStatus[0]
StatusDescriptions[0]
OperationalStatus[1]
StatusDescriptions[1]
Memory module status is unknown
 0 (Unknown)
 Memory module status:
Unknown
 <not populated>
 <not populated>
Memory module is operating
properly
 2 (OK)
 GOOD, Inuse
 <not populated>
 <not populated>
Memory module is present but is not
currently used by the operating
system
 2 (OK)
 GOOD
 15 (Dormant)
 Used For Resiliency
Memory module present but is not
configured correctly
 0 (Unknown)
 Configuration Error
 <not populated>
 <not populated>
Memory module is present but is
partially used
 2(OK)
 GOOD
 32768 (Partial)
 Partially In Use
Memory module does not match
 0 (Unknown)
 Does Not Match
 <not populated>
 <not populated>
Memory module not supported
 0 (Unknown)
 Not Supported
 <not populated>
 <not populated>
Memory module is not present
 0 (Unknown)
 Not Present
 <not populated>
 <not populated>
