7 System memory

7-1 Overview

This provider implements the HP Memory Profile and HP Memory Physical Asset Profile to represent

system memory in ProLiant systems.

See the HP Advanced Memory Protection Technologies (TC060104TB) and product documentation

for your ProLiant server (available at http://www.hp.com).

The following profiles are implemented, and the following files are installed by this provider.

Table 7-1 Overview

Implemented Profiles

 HP Memory Profile 1.0

 HP Memory Physical Asset Profile 1.0

 HP Location Profile 1.0

Provider Installation Files

 HPWmiMemory.DLL

 HPWmiMemoryEvt.DLL

 HPWmiMemoryEvtMsg.DLL

 HPWmiMemory.mof

 HPMemEvtCons.mof

 HPErrorMetaInstance.mof

 HPWmiEvent.mof

 HPWmiEvtCons.mof

7-2 Use cases

The following sections contain information and diagrams to facilitate understanding of the specific

implementation of the memory providers on ProLiant server platforms. These diagrams are intended to

enhance, but not replace, the use cases shown in the HP Memory Physical Asset Profile to define the

specifics of the class implementation.

The following initial subsection discusses the classes implemented for ProLiant hardware. A class

diagram shows the memory providers class structure from an implementation viewpoint.

The following subsequent subsections describe the hardware and software (memory providers)

containment hierarchy for ProLiant server platforms. The containment hierarchy describes the

relationships between the following:

 Memory modules (DIMMs)

 Memory module slots (the connectors or sockets where Memory Modules are installed)

 Memory boards (a circuit board on which there are memory module slots)

 Memory board slots (the connectors or sockets where Memory Boards are installed)

 The system chassis
