5-3-15 HP_ElementLocation
HP_ElementLocation is used to represent an association between CIM_Location and
CIM_ManagedElement. The Windows® implementation class is HP_WinFanElementLocation.
Table 5-16 Class: HP_ElementLocation
Property name
Property implementation
Element
References CIM_ManagedElement
PhysicalLocation
References CIM_Location
5-3-16 CIM_ConfigurationCapacity
CIM_ConfigurationCapacity is used to model fan configuration capacity on ProLiant Servers. The
Windows® implementation class is HP_WinFanConfigurationCapacity. There is one instance of this
class on systems modeling fan configuration capacity.
Table 5-17 Class: CIM_ConfigurationCapacity
Property name
Property implementation
CIM_ManagedElement
Caption
Fan Configuration Capacity
Description
This describes the number of fans that can be
configured.
ElementName
Fan Configuration Capacity
CIM_PhysicalCapacity
Name
Unique identifier for this fan configuration capacity
CIM_ConfigurationCapacity
ObjectType
3 (Fans)
Increment
1
MaximumCapacity
Maximum number of fans
MinimumCapacity
Minimum number of fans
5-3-17 CIM_ElementCapacity
CIM_ElementCapacity is used to represent an association between CIM_ConfigurationCapacity and
the computer system chassis that contains this configuration capacity. The Windows® implementation
class is HP_WinFanElementCapacity.
