HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 5-13 Class: HP_RealizesFan
Property name
Property implementation
Dependent
References HP_Fan
5-3-13 HP_SystemPhysicalFan
HP_SystemPhysicalFan is used to represent an association between HP_FanModule and the computer
system that contains this fan.
Table 5-14 Class: HP_SystemPhysicalFan
Property name
Property implementation
GroupComponent
References HP_ComputerSystemChassis
PartComponent
References HP_FanModule
5-3-14 HP_Location
HP_Location is used to model fan locations on ProLiant servers. The Windows® implementation class
is HP_WinFanLocation.
Table 5-15 Class: HP_Location
Property name
Property implementation
CIM_ManagedElement
Caption
Fan n, where n represents the fan position printed on
the system labeling.
Description
The location of the fan n. Please refer to fan position n
printed on the system.
ElementName
Fan n, where n represents the fan position printed on
the system labeling.
CIM_Location
Name
Unique identifier for this fan location instance
PhysicalPosition
n, where n represents the fan position printed on the
system.
HP_Location
ElementLocationTag
Fan n, where n represents the fan position printed on
the system.
ElementLocationTagDesc
0 (HoodTag)
