Table 5-11 Class: HP_FanSlot
Property name
Property implementation
CIM_PhysicalElement
CreationClassName
―HP_FanSlot‖
Tag
Fan n, where n represents the physical lot number
Description
Fan n, where n represents the physical lot number
ElementName
Fan n, where n represents the physical lot number
CIM_PhysicalConnector
ConnectorLayout
7 (Slot)
ConnectorPinout
―Custom Fan Slot‖
ConnectorType
76 (Proprietary)—Custom Fan slot
CIM_Slot
Number
The physical fan slot number
SupportsHotPlug
 true—If slot supports hot plug operations
 false—If slot does not support hot plug operations
VendorCompatibilityStrings
―HPQ:Fan‖
HP_FanSlot
5-3-11 HP_FanInSlot
HP_FanInSlot is used to represent an association between HP_FanModule and HP_FanSlot that
contains this fan.
Table 5-12 Class: HP_FanInSlot
Property name
Property implementation
Antecedent
References HP_FanSlot
Dependent
References HP_FanModule
5-3-12 HP_RealizesFan
HP_RealizesFan is used to represent an association between HP_Fan and HP_FanModule that realizes
this fan.
Table 5-13 Class: HP_RealizesFan
Property name
Property implementation
Antecedent
References HP_FanModule
