HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 5-10 Class: HP_FanModule
Property name
Property implementation
StatusDescriptions[0]
 ―Fan is operating properly‖—If
OperationalStatus[0] is 2 (OK)
 ―Fan has failed‖—If OperationalStatus is 6 (Error)
HealthState
 5 (OK)—If fan is operating properly;
 20 (Major Failure)—If fan has failed
Name
Fan n, where n represents the number of the fan
instance
CIM_PhysicalElement
CreationClassName
―HP_FanModule‖
Tag
Unique identifier for this fan module instance
CIM_PhysicalPackage
PackageType
7 (Fan)
RemovalConditions
3 (Removable when off)
4 (Removable when on or off)
HP_Fan
5-3-10 HP_FanSlot
HP_FanSlot represents fan slot on ProLiant Servers. There is an instance of this class for each fan slot in the
system, whether or not the slot is occupied.
Table 5-11 Class: HP_FanSlot
Property name
Property implementation
CIM_ManagedElement
Caption
Fan n, where n represents the physical lot number
CIM_Managed SystemElement
HealthState
 5 (OK)—If fan is operating properly
 20 (Major Failure)—If fan has failed
Name
Fan n, where n represents the physical lot number
OperationalStatus[0]
 2 (OK)—If fan is operating properly
 6 (Error)—If fan has failed
StatusDescriptions[0]
 ―Fan is operating properly‖—If
OperationalStatus[0] is 2 (OK)
 ―Fan has failed‖—If OperationalStatus is 6 (Error)
 ―Fan slot is empty‖ – if OperationalStatus[0] is
2(OK)
