HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 5-8 Class: HP_HostedCoolingCollection
Property name
Property implementation
Antecedent
References HP_ComputerSystem
Dependent
References HP_CoolingCollection
5-3-8 HP_SystemFan
HP_SystemFan is used to represent an association between HP_Fan and the computer system that
contains this fan. The Windows® implementation class is HP_WinSystemFan.
Table 5-9 Class: HP_SystemFan
Property name
Property implementation
GroupComponent
References HP_ComputerSystem
PartComponent
References HP_Fan
5-3-9 HP_FanModule
HP_FanModule is used to model the physical fans on ProLiant Servers. The Windows®-specific
implementation class is HP_FanModule.
NOTE: Fan numbers for existing instances do not change when other fans are added and removed.
Table 5-10 Class: HP_FanModule
Property name
Property implementation
CIM_ManagedElement
Caption
Fan n, where n represents the number of the fan
instance
Description
Fan n provides cooling for FanType. StatusDescription
where n represents the number of the fan instance,
FanType represents the corresponding string value of
the FanType enumeration and StatusDescription
represents the value of StatusDescriptions[0]
ElementName
Fan n, where n represents the number of the fan
instance
CIM_Managed SystemElement
OperationalStatus[0]
 2 (OK)—If fan is operating properly
 6 (Error)—If fan has failed
