5-3-3 HP_CoolingRedundancySet
HP_CoolingRedundancySet is used to model fan redundancy sets on ProLiant servers. The Windows®
implementation class is HP_WinCoolingRedundancySet.
Table 5-4 Class: HP_CoolingRedundancySet
Property name
Property implementation
CIM_ManagedElement
Caption
Cooling Redundancy Set n
n represents the number of the redundancy set instance
Description
Cooling Redundancy Set n is collection of fault tolerant
fans that provide redundant cooling.
n represents the number of the redundancy set instance
ElementName
Cooling Redundancy Set n, where n represents the
number of the redundancy set instance
CIM_SystemSpecificCollection
InstanceID
Unique identifier for this cooling redundancy instance
CIM_RedundancySet
MaxNumberSupported
Represents the maximum number of fans supported for
this redundancy set
MinNumberNeeded
Represents the minimum number of fans needed to
function
TypeOfSet
3 (Load Balanced)
LoadBalanceAlgorithm
0 (Unknown)
RedundancyStatus
 0 (Unknown)—If the redundancy status is unknown
 2 (Fully Redundant)—If the all fans in the set are
operating properly and enough to achieve
redundancy
 3 (Degraded Redundancy)—If there are at least
enough fans for the redundancy set to provide
cooling, but fans have failed
 4 (Redundancy Lost)—If there are not enough fans
required to achieve redundancy, but enough for the
redundancy set to provide cooling
 5 (Overall Failure)—If there are not enough fans
operating properly for the redundancy set to
provide cooling.
