Table 5-2 Class: HP_Fan
Property name
Property implementation
Caption
Fan n, where n represents the number of the fan
instance.
Description
Fan n provides cooling for fantype. statusdescription.
n represents the number of the fan instance, fantype
represents the corresponding string value of the
FanType enumeration and statusdescription represents
the value of StatusDescriptions[0]
ElementName
Fan n, where n represents the number of the fan
instance.
CIM_ManagedSystemElement
OperationalStatus[0]
 2 (OK)—If fan is operating properly;
 6 (Error)—If fan has failed
StatusDescriptions[0]
 Fan is operating properly—If OperationalStatus[0]
is 2 (OK)
 Fan has failed—If OperationalStatus is 6 (Error)
HealthState
 5 (OK)—If fan is operating properly
 20 (Major Failure)—If fan has failed
Name
Fan n, where n represents the number of the fan
instance.
CIM_LogicalDevice
CreationClassName
HP_WinFan
DeviceID
Unique identifier for this fan instance
SystemCreationClassName
HP_ComputerSystem.CreationClassName
SystemName
HP_ComputerSystem.Name
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_CoolingDevice
ActiveCooling
true
CIM_Fan
VariableSpeed
 true—If fan supports variable speed
 false—If fan does not support variable speed or is
unknown
HP_Fan
FanType
Enumeration describing the type of fan (see MOF)
