by the deployment engine within the appliance. It is used to communicate with a target server’s
deployment interface IP address.
This configuration only requires the first network adapter on the VM.
Select OK or Logout. Selecting the OK button applies the information you have supplied. Allow
15 minutes while the appliance configures and reboots to complete the configuration. Selecting
the Logout button exits from the appliance without saving the appliance networking information.
NOTE: The password you set for the account administrator will be applied even if you select
Logout.
NOTE: After your initial login to the appliance via the vSphere Client or Hyper-V Manager
Console, you may use a browser to access the appliance. However, you may also access the
appliance via the Console if you wish.
Configure Deployment IP on a different network
To begin configuring the Deployment IP, select the 2 Deployment network interface in the Appliance
Networking screen. A set of fields is displayed for you to configure the Deployment IP (as shown
below).
IMPORTANT: Once the Deployment IP address is set during first time setup it cannot be changed.
Figure 10 Deployment IP configuration on a different network edit fields
26 Installing your Insight Control server provisioning appliance for the first time
