Figure 6 Set a new password
IMPORTANT: Make sure you remember the new administrator password. Note that there
is a password reset service if needed.
Configure appliance networking
HP Insight Control server provisioning requires you to configure an Appliance IP and a Deployment
IP and corresponding netmask. See “Appliance networking considerations” (page 10) for additional
information. During first time setup you can configure the Appliance IP and Deployment IP on a
single NIC or you can configure the Appliance IP and Deployment IP on different NICs. Instructions
for single NIC and multi-NIC configuration are provided below.
You can switch from single NIC to multi-NIC if you need to (see the online help topic “Change
from single NIC to multi-NIC” for details).
IMPORTANT: Once you set the Deployment IP address during first time setup it cannot be changed
even if you switch between single and multi-NIC.
Configure appliance networking from the Appliance Networking screen (shown below).
22 Installing your Insight Control server provisioning appliance for the first time
