HP Insight Control Server Provisioning 7.2 Online Help

Table 76 Media Server information
This is the IP address or host name of the Windows file share that is hosting the Media Server.File share host
This is the name of the Windows file share on the Media Server.File share name
The Windows user name that has access to the file share.File share user
The IP address of the system hosting the HTTP media server.HTTP server host
The virtual directory on the HTTP server that points to the lower level folder where all the media
are stored.
HTTP server path
Table 77 DHCP information
This will read installed if a WinPE file has been uploaded to the appliance, and not
installed if the appliance has no WinPE file in its database.
WinPE file
Insight Control server provisioning comes with a DHCP server embedded in the appliance. You
may select the DHCP capability of the appliance that is best for your environment.
Service provided by
appliance
• DHCP – enabled on the appliance
• None – DHCP is disabled
The starting address to use for IP address assignments. This is only displayed if DHCP is enabled.Base IP address
The netmask for the DHCP server on the appliance. This is only displayed if DHCP is enabled.Netmask
The gateway for the DHCP server on the appliance. This is only displayed if DHCP is enabled
and is an optional field.
Gateway
Table 78 Product Keys information
This is the total number of product keys defined on the appliance. Currently, only Microsoft
product keys are supported.
X Keys
To see the list of product keys currently set on the appliance, click the Product Keys title.
Table 79 Facility Custom Attributes information
This is the total number of custom attributes defined at the facility level for this appliance.X Facility Custom
Attributes
To see the list of facility level custom attributes currently set on the appliance, click the Facility
Custom Attributes title.
Table 80 OS Deployment Settings information
The default service OS to be used when adding bare metal servers to Insight Control server
provisioning. In order to discover a bare metal system, that system is usually booted into a special
Default service OS
service OS. The service OS has just enough software on it to report various details about the
server back to the management software and deploy a production operating system.
This is the customer-provided name of your facility.Facility name
10.18 Product key settings information
Table 81 Product Keys information
This is the Windows version the product key is for. Currently, only Microsoft product keys are
supported.
Windows Version
Product keys are stored as facility-level custom attributes. This is the name of the custom attribute
for this product key.
Custom Attribute
Name
This is the product key for the Windows Version specified.Value
94 Settings
