HP Insight Control Server Provisioning 7.2 Online Help

10.15 Facility custom attributes information
Table 74 Facility custom attributes information
The name of the name/value custom attribute pair associated with the facility.Name
The value of the name/value custom attribute pair associated with the facility.Value
10.16 Import a certificate
Reserved for DocNotes
Use this procedure to import a certificate that you receive from a certificate authority as the result
of sending a certificate signing request. For more information, see Create a certificate signing
request.
Prerequisites
• Minimum required privileges: Infrastructure Administrator
• Ensure that no other users are logged in to the appliance
Procedure 51 Importing certificate
1. Select Actions→Import certificate in the Settings screen.
2. Copy the certificate text and paste it into the text area designated by Paste a certificate to
import it into the appliance.
3. Click OK.
4. After the appliance web server restarts and reconnects, log in to the appliance.
10.17 Overview screen for settings
• Table 75 (page 93)
• Table 76 (page 94)
• Table 77 (page 94)
• Table 78 (page 94)
• Table 79 (page 94)
• Table 80 (page 94)
Table 75 Appliance networking information
The appliance has the following minimum requirements:Appliance health
• LAN – 1 Gb/s
• CPU – 4 @ 2 GHz
• Memory – 16 GB
This is the host name of the appliance. If you are supplying a DNS server, this host name must
be fully qualified. From a supported browser, you can navigate to the appliance using this name
or by using the appliance IP address.
Host name
This is the appliance IP address.IP address
This will read IC server provisioning for Insight Control server provisioning.Model
The current appliance date and time. This is the date and time used by the UI. The time zone is
UTC.
Date/time
The version of Insight Control server provisioning currently running.Version
To see additional appliance settings information, click the Appliance title.
10.15 Facility custom attributes information 93
