Table 69 Media Server information (continued)
Each label within a host name must begin and end with an alphanumeric
character and have a maximum length of 63 characters.
Default value: None
Required: Yes
File share name Description: This is the name of the Windows file share that is hosting the Media Server.
Data type: A text string that identifies the Windows share and path portion of an SMB URI
(/<ShareName>/<DirectoryPath>/). This must resolve to the Media Server
contents. The string you enter must have a leading /. A trailing / is optional.
Default value: None
Required: Yes
File share user Description: This is the Windows user name that has access to the file share.
Default value: None
Required: Yes
File share password Description: The password associated with the File share user.
Default value: None
Required: Yes
HTTP server host Description: The IP address of the Windows system hosting the media server.
Default value: None
Required: Yes
HTTP server path Description: The virtual directory that points to the lower level folder where all the media
are stored.
Default value: None
Required: Yes
10.12.3 Edit Media Server settings screen buttons
Table 70 Edit Media Server screen buttons
Selecting OK saves the Media Server settings with the information as entered on the Edit Media
Server page.
OK
Exits the Edit Media Server screen without saving any edits.Cancel
10.13 Editing OS deployment settings
Table 71 OS Deployment Settings edit fields
Default service OS Description: The default service OS to be used when adding bare metal servers to Insight
Control server provisioning.
In order to discover a bare metal system, that system is usually booted into a
special service OS. The service OS has just enough software on it to report
various details about the server back to the management software and deploy
a production operating system.
Default value: LinuxPE
Required: Yes
Facility name Description: This is the customer-provided name of your facility.
Data type: The Facility name has a maximum length of 29 characters.
Default value: Appliance
Required: Yes
10.13 Editing OS deployment settings 91
