10.8.5 Edit appliance networking settings screen buttons
Table 61 Edit appliance networking screen buttons
Selecting OK saves the appliance networking settings with the information as entered on the
Appliance Networking page.
OK
Exits the Appliance Networking screen without saving any edits.Cancel
10.9 Editing DHCP settings and uploading WinPE
• “To edit DHCP settings” (page 87)
• “To create a WinPE and upload to your appliance” (page 87)
• “About uploading WinPE” (page 87)
• “Edit DHCP input fields” (page 88)
• “Edit DHCP settings screen buttons” (page 88)
Procedure 48 To edit DHCP settings
1. Select Settings from the main menu.
2. Select in the DHCP panel.
3. Enter the network information for your facility as described in “Edit DHCP input fields” (page 88)
and “Edit DHCP settings screen buttons” (page 88).
Procedure 49 To create a WinPE and upload to your appliance
1. Select Settings from the main menu.
2. Select in the DHCP panel.
3. Download the HP Insight Control server provisioning WinPE image generation utility by
selecting Download HP Insight Control server provisioning WinPE image generation utility.
4. Create a WinPE file as described in the HP Insight Control Server Provisioning Installation
Guide available at http://www.hp.com/go/insightcontrol/docs.
5. In the WinPE upload area of the Settings DHCP screen, either drag and drop your WinPE file
to the box or select Upload file to browse to the WinPE file.
10.9.1 About uploading WinPE
WinPE (Windows Preinstallation Environment) is the service OS for the Windows operating system.
This is a special purpose operating system that is used when provisioning a target server with a
Windows OS. WinPE runs entirely in system memory on the target server and prepares the target
server for Windows operating system installation.
Your appliance cannot be delivered with WinPE preinstalled. WinPE must be generated external
to the appliance and then uploaded. This step is required for most users as part of the initial
appliance setup and each time your appliance is updated.
Because an uploaded WinPE is required in order to PXE boot a server into WinPE, the only
circumstances where a WinPE upload is not required are:
• only Linux and ESXi installations will be performed, and no Windows image capture or deploy
will be done
• only Gen8 or newer servers with Intelligent Provisioning will be used (no PXE), and no Windows
image capture or deploy will be done
