HP Insight Control Server Provisioning 7.2 Online Help

• Select Disabled if you want to deny HP Support access to your appliance.
4. Click OK.
Your options are saved and you are returned to the Settings screen.
10.8 Editing appliance networking settings
• “To edit appliance networking settings” (page 85)
• “Editing appliance networking general information” (page 85)
• “Editing appliance networking IPv4 information” (page 85)
• “Editing appliance networking DNS information” (page 86)
• “Appliance time and place information” (page 86)
• “Edit appliance networking settings screen buttons” (page 87)
Procedure 47 To edit appliance networking settings
1. Select Settings from the main menu.
2. Select from the Appliance panel.
10.8.1 Editing appliance networking general information
Table 57 General input fields on the Appliance Networking screen
Appliance host
name
Description: This is the host name of the appliance. If you are supplying a DNS server, this
host name must be fully qualified. From a supported browser, you can navigate
to the appliance using this name or by using the appliance IP address.
Data type: Host names are composed of a series of labels concatenated with periods
(<label>.<label>, etc.).
Host names may contain alphanumeric characters, hyphens (-), and periods
(.).
The host name has a maximum length of 255 characters.
Each label within a host name must begin and end with an alphanumeric
character and have a maximum length of 63 characters.
Default value: None
Required: Yes
10.8.2 Editing appliance networking IPv4 information
Table 58 IPv4 input fields on the Appliance Networking screen
Appliance IP
address
Description: This is the IP address you are assigning to this appliance. Use this to browse to
the appliance.
Default value: None
Required: Yes
Deployment IP
address
Description: This is the IP address used by the deployment engine within the appliance. It is
used to communicate with a target server’s deployment interface IP address and
its iLO IP address. This should be on the same network as the appliance IP
address.
This is the IP address to provide to HP Matrix Operating Environment.
IMPORTANT: If you change this IP address, the appliance will become
unavailable for up to 20 minutes while it is reconfigured, followed by an
appliance reboot. In addition, all target servers’ agents will have to be updated
with the new IP address. HP does not recommend changing this IP address
unless absolutely necessary.
10.8 Editing appliance networking settings 85
