HP Insight Control Server Provisioning 7.2 Online Help

Table 52 IPv4 appliance information (continued)
CAUTION: Relying on randomly assigned DHCP addresses can result in connectivity issues
and failures throughout the environment when the DHCP server changes the address assigned
to the appliance.
This is the IP address assigned to this appliance. Use this IP address to browse to the appliance
via a supported browser.
Appliance IP
address
This is the IP address used by the deployment engine within the appliance. It is used to
communicate with a target server’s deployment interface IP address and its iLO IP address. This
should be on the same network as the appliance IP address.
Deployment IP
address
This is the IP address to provide to HP Matrix Operating Environment.
This is the IPv4 mask representing the bits reserved for network identification (for example,
255.255.255.0) , or the Classless Internet Domain Routing (CIDR) mask representing the number
of bits reserved for network identification.
Subnet mask or
CIDR
This is the IP address for the network interface on your router.Gateway address
Table 53 DNS appliance information
The IP address of your preferred DNS server.Preferred DNS
server
The IP address of your alternate DNS server.Alternate DNS
server
Table 54 Time and Place appliance information
The date and time according to the browser you are running the appliance in.Current date/time
The time zone of the appliance.Timezone
The language the appliance is set to.Locale
NOTE: The IC server provisioning appliance uses the locale set in your browser. For first release,
only English is supported.
10.3 Create a certificate signing request
Reserved for DocNotes
This is the sequence of events for a certificate authenticated by a Certificate Authority (CA):
1. Create a certificate signing request.
2. Send the certificate signing request to the CA; the CA stipulates how this is done.
3. Receive the certificate from the CA; the CA stipulates how this is done also.
4. Import the certificate.
Prerequisites
• Minimum required privileges: Infrastructure Administrator
• Gather the information for the request as required by the CA.
• You must know the certificate authority’s challenge password.
Procedure 43 Creating a certificate signing request
1. Select Actions→Create certificate signing request in the Settings screen.
2. Enter the required information shown in Table 55 (page 82)
3. Enter the certificate signing request attributes; see Table 55 (page 82).
4. Enter any optional information shown in Table 55 (page 82).
5. Click OK.
6. Transfer the certificate signing request to the CA.
10.3 Create a certificate signing request 81
