• Custom attributes are associated with servers, your facility, and OS Build Plans. If the same
custom attribute name is defined at multiple levels, conflicts are resolved by precedence.
Custom attribute precedence, highest to lowest
1. Servers
2. Facility
3. OS Build Plans
For example, if a custom attribute is defined for a server and defined for an OS Build Plan,
the custom attribute value defined for the server would be used.
6.5 Deleting scripts
Remove any script from the scope of the Insight Control server provisioning appliance by first
selecting the script from the master pane list of scripts, and then selecting Actions→Delete. This will
delete the script from the appliance database.
NOTE: Scripts supplied by Insight Control server provisioning are read only and may not be
deleted. These are identified by the HP-provided field on the Overview General panel showing
Yes.
6.6 Editing scripts
The Edit Script screen is available by selecting Actions→Edit from any script screen, or by selecting
from the script Overview screen.
If the HP-provided field on the Overview General panel shows Yes, the script was created by HP
and is read only. Save the script to a new name by selecting Actions→Save as from the Overview
screen and then edit that copy.
• “Navigating the Edit script screen” (page 66)
• “Input fields on the Edit script screen” (page 66)
• “Edit script screen buttons” (page 67)
6.6.1 Navigating the Edit script screen
If you come to the Edit script screen from the Overview screen, you will be taken to a section
depending on the you selected: General or Script.
TIP: You can edit other sections of the Edit screen by scrolling – all sections are available to edit.
6.6.2 Input fields on the Edit script screen
Table 30 Input fields on the Edit script screen
Name Description: This is the unique label that will be associated with the script. The name of the
script appears in the master pane list on the Scripts screen (select Scripts from
the main menu) and is what you use to identify a script when you add it as a
step to an OS Build Plan.
Data type: Character string
The Name may not begin with a space or punctuation.
The Name cannot contain: <, >, &, newlines, tabs, slashes (/), or backslashes
(\).
The Name must be unique.
Default value: None
Required: Yes
66 Scripts
