Table 23 Steps
This Build Plan will execute the steps in the order shown, beginning with step 1.Step
This is the name of the specific resource used in this step. For example, if the step is a script, this
is the script name.
Name
Table 24 History
This is the date and time the Action occurred.Date
Action Description: This is what happened with the Build Plan.
Examples:
• Create OS Build Plan
• Run OS Build Plan
• Update OS Build Plan
Table 25 Custom Attributes
Name Description: This is the name of the name/value custom attribute pair associated with this
specific Build Plan.
Default values: The OS Build Plans provided by Insight Control server provisioning have two
custom attributes preset: OSType and archType. These values are required
for the HP Matrix Operating Environment.
This is the value of the name/value custom attribute pair associated with this Build Plan.Value
5.13 Requirements for OS Build Plans
• “General requirements” (page 60)
• “Requirements for OS Build Plans that install operating systems” (page 60)
• “Requirements for OS Build Plans that install firmware or SPPs” (page 60)
5.13.1 General requirements
• The Insight Control server provisioning appliance network interface must be able to access
the network your target servers are on.
5.13.2 Requirements for OS Build Plans that install operating systems
• The appropriate OS distribution files must be on the Media Server.
• For Windows installations, you must have the Windows product keys defined on the Settings
page as described in “Editing product key settings” (page 92).
5.13.3 Requirements for OS Build Plans that install firmware or SPPs
• You must install the HP Service Pack for ProLiant (SPP) on your Media Server.
5.14 Running an OS Build Plan
• To run an OS Build Plan
• Table 26 (page 61)
• Table 27 (page 61)
• “Configuring static networking information” (page 62)
• Table 28 (page 62)
