HP Insight Control Server Provisioning 7.2 Online Help

Table 20 Input fields for general information on the Edit OS Build Plan screen (continued)
Examples:
ProLiant OS - RHEL6.2 x64 Scripted Installation•
TIP:
See “Use HP’s naming convention for Build Plans” (page 48) for tips on naming Build Plans.
Description Description: Use this text area to create a short, meaningful synopsis of what this Build Plan
does.
Data type: Character string
The Description has a maximum length of 500 characters.
Default value: None
Required: No
Examples:
• Install RHEL 6.2 on a server.
Type Description: Describes the type of action being performed by the Build Plan, such as the
operating system this Build Plan will deploy to target servers. Build Plans that
do not deploy an OS will read Other.
This field does not affect the operation of the Build Plan, but might be used by
other HP software products that will integrate with Insight Control server
provisioning. As a result, HP recommends setting this appropriately.
Default value: Other
Required: Yes
5.7.3 Editing OS Build Plan steps
• “To add or edit a step” (page 55)
• “To reorder steps” (page 56)
• “To edit the parameters associated with a step” (page 56)
• “To delete a step” (page 56)
Procedure 27 To add or edit a step
1. From the Edit OS Build Plan screen, select Add steps or in a step row.
2. Select the type of step you’d like to add from the Type menu. Selections are:
• Run script – a script in the appliance database will be run.
• Deploy package – a package in the appliance database will be placed on the target
server and decompressed (unzipped).
• Capture configuration file – a text file from the target server will be captured and stored
in the appliance database.
• Deploy configuration file – a configuration file will be placed on the target server so it
may be used for the remainder of the installation.
The selection in the Type menu controls what is displayed in the Step table.
If you select Capture configuration file, there will be no Step table; you only need to specify
the full path name of the configuration file that will be captured from the target server.
3. Select the step to add. You may type the item name, or portion of the name, to search through
the list of available items, or you may select from the Step table. You may only select one item
at a time to add, however you may use the Add+ button to continue adding steps.
If there is a description for the item selected, it will be displayed in the Description text field.
If you select Capture configuration file, there will be no Step table; you only need to specify
the full path name of the configuration file that will be captured from the target server.
5.7 Editing OS Build Plans 55
