HP Insight Control Server Provisioning 7.2 Online Help

Table 19 Optional custom attributes of interest for OS Build Plans (continued)
Example valuesDescriptionName
encrypted.
CAUTION: HP strongly recommends
changing this password before
deploying to any servers.
For Linux and ESX deployment:
“noapci”, “root=LABEL=/”, “quiet”,
“splash”
Used to specify additional arguments
to the kernel where the installation is
running.
kernel_arguments
NOTE: For servers with B120i and
B320i controllers, the custom attribute
kernel_arguments must be set to
blacklist=ahci for Red Hat
installations or
broken_modules=ahci for SLES
installations.
Used to set the “root” password on a
new installation. By default, ProLiant
root_password
Build Plans expect a string that has
already been encrypted. You can
modify the configuration file so it will
accept an unencrypted value.
The default value is
ChangeMe123!
encrypted.
CAUTION: HP strongly recommends
changing this password before
deploying to any servers.
“sda”, “hdc”, “cciss/c0d1”Determines which disk to install the
OS to.
boot_disk
5.5.3 Rules for custom attributes
• The name may not contain spaces or special characters. It may contain numbers, underscores,
and dashes.
• The value can contain special characters and spaces, and you may also leave it blank. Special
characters might require double quotes if the value will be executed, for example “echo hello
> temp.txt”.
• You may not use a custom attribute within a custom attribute value.
• You may not have duplicate custom attribute names for an individual OS Build Plan.
• Custom attributes are associated with servers, your facility, and OS Build Plans. If the same
custom attribute name is defined at multiple levels, conflicts are resolved by precedence.
Custom attribute precedence, highest to lowest
1. Servers
2. Facility
3. OS Build Plans
For example, if a custom attribute is defined for a server and defined for an OS Build Plan,
the custom attribute value defined for the server would be used.
NOTE: Custom attributes set at the OS Build Plan level are at the lowest precedence.
5.5 Custom attributes for OS Build Plans 53
