Table 16 Server statuses (continued)
Provisioning failed on this server. It is available for provisioning.
The server is unreachable. This means HP Insight Control server provisioning is not able to
communicate with the server.
Server status is unknown to Insight Control server provisioning.
4.7.4 Configuring server networking
To configure target server networking configuration from the Server Overview page, select
Actions→Configure network.
For additional information, see “Network configuration for servers” (page 40).
4.8 General information for a single server
• “Fields on the Server General screen” (page 45)
• “Configuring server networking” (page 46)
4.8.1 Fields on the Server General screen
Table 17 General information for servers
The name of this server, fully qualified or not.Host name
The server state may be one of the following values:Server state
• OK – the server is managed and in a normal state.
• UNREACHABLE – the server cannot be contacted by the Insight Control server provisioning
appliance.
• MAINTENANCE – the server has booted to a service OS and is running a maintenance version
of the SA OGFS agent. Servers in maintenance mode are typically waiting to be provisioned
or are currently being provisioned.
Optional customer-provided text that gives extra information about this server.Description
The ProLiant server or blade server type.Hardware model
The operating system type and version currently running on the server.Operating system
This area provides information on the networking for each of the Network Interface Controllers
(NICs) on this server:
Network
• Name – the name assigned to the NIC by the operating system.
• IP address – the IP address of the NIC. If there is no IP address listed, the NIC has either not
been configured or not connected to the network.
• Subnet mask – the network identification for this NIC.
• Network controller – the type of network controller
• Speed – the speed of the network
• Duplex – indicates FULL or HALF
• MAC Address – the hardware address of the NIC.
• DHCP – shows whether the IP address was assigned using DHCP
The production NIC IP address used to communicate with Insight Control server provisioning.Deployment
interface
The IP address of the server’s iLO.iLO IP address
The number of physical CPU chips of each type on the server.CPU sockets
4.8 General information for a single server 45
