Table 13 History
The name of a job that was run on the server, for example, the name of an OS Build Plan.Provisioning Task
The date and time the job was started. This is a link to this job’s page.Job
NOTE: Because the Jobs page can only display a finite number of jobs, it’s possible a job listed
in History will be too old to still exist on the Jobs page. In that case the time and date will not be
a link to the Jobs page.
Table 14 Custom Attributes
The name of the name/value custom attribute pair associated with this specific server.Name
To view the Source and Value for a custom attribute, select next to the custom attribute name.
The Source is the level at which this custom attribute was defined. See “Custom attributes for
servers” (page 35) for more information.
4.7.2 Information displayed for multiple servers
The multi-select Overview screen for servers allows you to view the selected servers by various
categories and features.
To view the multi-select server Overview screen, select more than one server from the left side
master pane list of servers. You can select and deselect individual servers using Ctrl+left click.
Select a range of servers with Shift+left click.
Once you have multiple servers selected, you can use the Actions menu to take an action on all
the selected servers.
NOTE: Each number is a link that will display the details of the selected servers.
Table 15 Overview information for multiple servers
The number of servers selected per status. See “Server statuses” (page 44) for a description of
what the statuses mean.
Status
The number of servers selected per operating system installed on the server.OS
The number of servers selected per server hardware type.Model
The number of servers selected per number of processors on the server.Processors
The number of servers per amount of memory on the server.Memory
The number of servers per number of NICs on the server.NICs
4.7.3 Server statuses
Table 16 Server statuses
Server is provisioned and OK.
Job is running on a provisioned server.
This is an unprovisioned server ready to be provisioned.
Provisioning is in progress on an unprovisioned or provisioned server.
Reboot stage of a job running on a provisioned server.
