HP Insight Control Server Provisioning 7.2 Online Help

Table 9 Input fields for the server configure network Server Configuration screen (continued)
Examples: 8.8.8.8, 8.8.4.4
DNS suffix search
list
Description: A list of domains separated by commas, spaces, or both.
Data type: A list of period (.) separated character strings separated by spaces or commas.
Default value: None
Required: No
Examples: corp.net, my.corp.net
Windows
networking — Set
workgroup
Description: If you specify a workgroup, the server will be assigned that workgroup name.
Data type: A string up to 15 characters. The string may not contain special characters such
as: :, ;, >, <, *, +, =, |, ?, \, and “.
Default value: None
Required: No
Table 10 Selections for the server configure network NIC Configuration screen
NIC check boxes Description: Select the NICs you would like to modify. (If you do not configure a NIC on
this screen, its configuration will not be changed on the target server.) Then
select your IP assignment:
• DHCP – Make a DHCP request to get the IP address and other networking
information from a DHCP server. Choosing this might mean the system will
get a different IP address each time it boots.
• Static – Specify an IP address and network mask that will stay the same on
every boot. If you select this option, you are required to specify an IP address
and network mask. These fields will be displayed automatically if this option
is selected.
◦ IP addresses are numeric characters separated by periods (.) such as
192.168.1.1
This is displayed for a single server selection.
◦ Starting IP address: Servers will be assigned incremented static IP
addresses beginning with this address. This is displayed for multiple server
selection.
◦ A Network mask is the IPv4 mask representing the bits reserved for
network identification such as:
255.255.255.0
This is displayed for a single server selection.
Default value: DHCP
A View Generated Settings table will be displayed to show how the values will resolve for each
host if this server configuration is saved.
View button
• Display Name – The name displayed in the Servers master pane.
• Host Name – The server name you can set with the Host name text box in the Server
Configuration area of the Configure network screen.
• NIC – The name of the NIC as set within the server.
• MAC Address – The hardware address for the NIC.
• IP Address – The assigned static IP address or DHCP if the IP address will be assigned by
DHCP, depending on the selection for this NIC.
Table 11 Edit server network screen buttons
Saves the network configuration information for the server using the parameters on the screen.OK
42 Servers
