Table 2 HBA Custom Attribute Tags
DescriptionTag Name
The controller’s Word Wide Port Name (WWPN).BootWWPN-HBA0
The LUN to boot from.BootLUN-HBA0
The HBA’s World Wide Port Name (WWPN).WWPN-HBA0
NOTE: If this tag is specified, the configuration will be applied to the HBA with
the matching WWPN regardless of the order it was discovered.
If this tag is not specified, the configuration will be applied to the HBA number
that appears at the end of the BootWWPN-HBA tag. For example,
BootWWPN-HBA0 will be applied to first HBA, BootWWPN-HBA1 will be applied
to second HBA, and so on.
Set to one of the following values:SelectBootEnable-HBA0
BIOS configures the BootWWPN-HBA0 and BootLUN-HBA0 you specified
as the boot device.
1 –
BIOS configures the first disk drive it finds as the boot device.2 –
NOTE: If this tag is not specified, the default value is 1.
Set to one of the following values:HostAdapterBiosEnable-HBA0
Enables the ROM BIOS on the adapter. If you are booting from an FC
disk drive attached to the adapter, you must enable this setting.
1 –
Disables the ROM BIOS on the adapter, which frees space in upper
memory.
2 –
NOTE: If this tag is not specified, the default value is 1.
Below is sample job output for a server with a QLogic HBA.
QLogic HBAs:
Link Enable Selectable Primary Boot
HBA# Port HBA WWPN Status BIOS Boot Port Name LUN
---- ---- ----------------------- ------------ ------- ---------- ----------------------- ---
0 1 50:01:43:80:12:0B:FE:98 Online 1 0 50:01:43:80:11:36:E6:6A 1
1 2 50:01:43:80:12:0B:FE:9A Online 0 0 50:01:43:80:11:36:E6:6C 1
QLogic HBAs After Applying Configuration:
Link Enable Selectable Primary Boot
HBA# Port HBA WWPN Status BIOS Boot Port Name LUN
---- ---- ----------------------- ------------ ------- ---------- ----------------------- ---
0 1 50:01:43:80:12:0B:FE:98 Online 1 1 50:01:43:80:11:36:E6:6A 1
1 2 50:01:43:80:12:0B:FE:9A Online 1 1 50:01:43:80:11:36:E6:6C 1
3.3.7 Create a Windows scripted install OS Build Plan that installs Windows without
a product key
Windows can be installed without entering a product key during installation. After a 30-day grace
period, Windows activation will be required. The HP-provided Windows OS Build Plans require
a product key for installation.
Procedure 3 To create a Windows Build Plan to install Windows without a product key
1. Save a copy of the HP-provided configuration file that is referenced by the Build Plan you wish
to run. The file name is similar to Windows xxxx Standard Default Unattend.xml,
where xxxx is the Windows version.
2. Edit the copy and either remove or comment out the <ProductKey> line.
3. Save a copy of the HP-provided Build Plan and edit that copy.
4. Edit the step that references the unattend file and replace that step with the step edited earlier.
Be sure to preserve any parameters specified with the original configuration file.
