are supported on the HP Insight CMU management node see “Operating system support”
(page 21)
The following rpms must be installed on the HP Insight CMU management node. Any missing
rpms are flagged as dependencies when the HP Insight CMU rpm is installed and must be
installed to continue the installation.
a. expect
b. dhcp
c. tftp client
d. tftp server
e. Oracle Java Runtime Environment, update 33 or newer
f. tcl-8
g. OpenSSL
h. NFS
i. xterm
j. libX11
k. libXau
l. libXdmcp
m. perl-IO-Socket-SSL.
n. perl-Net-SSLeay
o. Samba (Required only if you intend to use HP Insight CMU Windows support.)
If you are using firewalls on the HP Insight CMU management node or GUI client workstation,
configure them to enable the following ports:
• On the HP Insight CMU management node:
External network interface◦
– RMI registry traffic (tcp ports 1099, 49150)
– Webserver port (tcp 80)
– ssh server (tcp 22)
◦ Internal (Admin/Compute) network interface
– – Allow all incoming and outgoing traffic. Admin NIC should be a trusted
interface or “Internal Zone”.
• On the GUI client workstation:
◦ – X Window export (tcp ports 6000 to 6063)
2. Download and install a supported version of Oracle Java. HP Insight CMU depends on Oracle
Java version 1.6 update 33 or later. Only the Java Runtime Environment (JRE) is required. To
download a supported JRE, go to: http://www.oracle.com/technetwork/java/index.html.
3. Install HP Insight CMU.
a. Install the HP Insight CMU rpm key:
# rpm --import /mnt/cmuteam-rpm-key.asc
NOTE: If you do not import the cmuteam-rpm-key a warning message similar to the
following is displayed when you install the HP Insight CMU rmp:
warning: REPOSITORY/cmu-v7.2-1.x86_64.rpm: Header V4 DSA/SHA1 Signature, key ID b59742b4: NOKEY
b. Install the HP Insight CMU rpm:
# rpm -ivh REPOSITORY/cmu-v7.2-1.x86_64.rpm
2.3 Installation procedures 23
