Ignite-UX and SAS Devices

Table of Contents

Introduction ......................................................................................................................................... 2

Agility and what Ignite-UX knows about SAS........................................................................................... 2

Improvements Made in Recent Ignite-UX Versions .................................................................................... 2

SAS RAID LUNs ................................................................................................................................... 3

Recovery and cold installation ............................................................................................................... 3

rx6600 and rx3600 SAS bay numbers .............................................................................................. 5

Placing a SAS device into a lower bay number ................................................................................... 6

Removing a SAS device when there are still devices in higher numbered bays ........................................ 8

What you can do with SAS devices ................................................................................................... 9

Information Ignite-UX can tell you to help during a recovery ................................................................ 10

Conclusion ........................................................................................................................................ 10

For More Information ......................................................................................................................... 11

Summary of content (11 pages)

PAGE 1
Ignite-UX and SAS Devices Table of Contents Introduction ......................................................................................................................................... 2 Agility and what Ignite-UX knows about SAS........................................................................................... 2 Improvements Made in Recent Ignite-UX Versions .................................................................................... 2 SAS RAID LUNs ..............................
PAGE 2
Introduction The following white paper is intended to explain how to use SAS disks with Ignite-UX to allow you to install and recover your systems without having to worry about Ignite-UX restrictions with SAS. Agility and what Ignite-UX knows about SAS SAS disks are identified to a system with a unique World-Wide Name (WWN) also known as a SAS address. The I/O stack on HP-UX 11i v2 internally associates that WWN to a hardware path.
PAGE 3
Release C.7.10 of Ignite-UX improved recovery by preserving hardware paths and legacy device file names under the sasd driver if hardware paths are available for swapping at installation time. As a result, you do not have to import LVM data volumes manually. SAS RAID LUNs You should be aware of the following information when you configure RAID LUNs. 2 Ignite-UX fully supports a configuration where only RAID LUNs are presented to a system. (This includes having a hot spare configured.
PAGE 4
- Swapping two or more SAS devices Permanently removing 4 a SAS device when there are still devices in higher numbered bays Moving a SAS device from one SAS HBA to another. Creating or deleting SAS RAID volumes post-installation 5 Once installed, if a SAS device must be replaced, you must use the sasmgr(1m) option replace_tgt to re-associate a SAS device with the hardware path of the device it replaces (it will be assigned a new hardware path since it has a different WWN). As of release C.7.
PAGE 5
rx6600 and rx3600 SAS bay numbers The following diagram shows the SAS bay numbers from highest to lowest on a HP Integrity rx6600 system. The following diagram shows the SAS bay numbers from highest to lowest on a HP Integrity rx3600 system. This white paper will not present SAS numbering information for external SAS enclosures or future systems that contain SAS devices, please consult the hardware documentation for those products to determine how SAS bays are numbered.
PAGE 6
Placing a SAS device into a lower bay number When rx3600 and rx6600 systems are shipped to you from HP, unfortunately the SAS bays are populated from 8 working downwards. Placing a new SAS device into a lower bay number will cause the hardware paths to change after a new cold-install or recovery session. Note: If you have never changed your SAS configuration before, you can safely move SAS devices downwards as a block 6.
PAGE 7
A problem happens if you were to re-install or recover this system 8, as the hardware paths would change to become: SAS Enclosure Bay # 4 5 6 7 8 Old Hardware Path 0/4/1/0.0.0.4.0 0/4/1/0.0.0.0.0 0/4/1/0.0.0.1.0 0/4/1/0.0.0.2.0 0/4/1/0.0.0.3.0 New Hardware Path 0/4/1/0.0.0.0.0 0/4/1/0.0.0.1.0 0/4/1/0.0.0.2.0 0/4/1/0.0.0.3.0 0/4/1/0.0.0.4.0 Since Ignite-UX (prior to version C.7.
PAGE 8
Removing a SAS device when there are still devices in higher numbered bays In this section we will look at removing SAS devices from a system. We will start with the following configuration: SAS Enclosure Bay # 1 2 3 4 5 Hardware Path 0/4/1/0.0.0.0.0 0/4/1/0.0.0.1.0 0/4/1/0.0.0.2.0 0/4/1/0.0.0.3.0 0/4/1/0.0.0.4.0 If we remove the device in Bay 3 we will be left with the following configuration: SAS Enclosure Bay # 1 2 Not Present 4 5 Hardware Path 0/4/1/0.0.0.0.0 0/4/1/0.0.0.1.0 0/4/1/0.0.0.3.0 0/4/1/0.
PAGE 9
What you can do with SAS devices You can replace SAS devices that have failed. You should, however, consult the SAS documentation and documentation for the revision of HP-UX you are running for the correct procedure for replacing SAS devices. Simply replacing a device while the system is up will create a new hardware path for the device (since it does not have the same WWN as the original device).
PAGE 10
Information Ignite-UX can tell you to help during a recovery To help you identify SAS devices during installation and recovery, Ignite-UX uses a device attribute called physical location. The physical location indicates the enclosure and bay where the device is located. For example, a physical location may be “SAS:ENC01:BAY01".
PAGE 11
For More Information The following relevant documents are available online at http://www.hp.com/go/hpux-core-docs Ignite-UX Administration Guide HP-UX 11i v[1|2|3] Installation and Update Guide HP-UX 11i v[1|2|3] Release Notes Managing Systems and Workgroups: A Guide for HP-UX System Administrators HP-UX System Administrator’s Guide Product information regarding Ignite-UX is available at: • http://www.hp.com/go/ignite-ux • http://www.hp.
