User Manual - A3661-90001

Unsolicited Event Log 6-47
Troubleshooting
0x910 Cache Recovery Failed A nonmirrored cache recovery was attempted but failed to
recover information for any cached LUNs. It does not apply to
a disk array with two SPs.
0x920 Hard Media Error This disk module has reported a media defect that could not
be cleared by the SP.
0x921 Host Vault Load Failed The SP encountered multiple errors while attempting to load
the cache image from disk. This message can indicate
multiple drive failures.
0x922 Host Vault Load
Inconsistent
The SP found inconsistencies in the cache image on the disk.
This can indicate a failure or abort of the cache dump.
0x923 Host Vault Load Failed
Bitmap OK
The SP successfully read the control portion of the cache
image on disk, but found the data portion to be incomplete.
This means that a failure or abort occurred during the cache
dump. Probably any LUNs with write-cached pages are
inaccessible and must be rebound. To identify such a LUN,
read message 0x90A in this table.
0x924 Host Vault Disks
Scrambled
The SP found the vault disks containing the cache image to
be in a different order than when the cache image was
dumped to disk. This means the disks were swapped at power
down. The disk modules must be restored to their original
order before the SP can load the cache image.
0x925 Single-board Cache;
Need PROM Update
This SP, which is operating in nonmirrored caching mode, has
too low a PROM revision level. Write caching cannot be
enabled.
0x926 RAID-3 Unit Cannot
Assign, No Memory
A RAID-3 LUN cannot be enabled because SP memory
allocated for RAID-3 processing is not available. This can
happen if the disk array is powered up after SP memory has
been removed, or when ownership of the LUN is transferred to
a peer SP that does not have enough memory.
0x928 RAID-3 Initialization
Failure, No Memory
No RAID-3 LUNs can be enabled because SP memory
allocated for RAID-3 processing is not available. This can
happen if the disk array is powered up after SP memory has
been removed, or when the ownership of the LUN is
transferred to a peer SP that does not have enough memory.
0x929 Front End Fibre Link
Down
The front end Fibre Channel interface failed or is inoperable.
0x937 Command Failed A command failed for the reason explained in the extended
status word.
Table 6-10 Error Codes (Continued)
Event code Event code name Description
