5-8 Support Tools Manager (STM)
7KHSK\VLFDOOD\RXWFRQWDLQVLQIRUPDWLRQDERXWWKHVWDWXVRIWKHGLVNVDQG/81V
Table 5-4 Disk State for the Map in the Information Log
Status Field
Values
Description
blank removed
Off off
Pow powering up
Unb unbound
Rdy ready
Reb rebuilding
Ena enabled
Bin binding
Fmt formatting
Eqz equalizing (with a hot spare)
Uns unsupported
Table 5-5 LUN Bind State for the Map in the Information Log
Status Field
Values
Description
blank disk is unbound
R-1 disk is bound to a RAID 1 LUN
R-3 disk is bound to a RAID 3 LUN
R-5 disk is bound to a RAID 5 LUN
R-10 disk is bound to a RAID 1/0 LUN
Hot disk is bound to a hot spare LUN
A0, B2, etc. LUN ownership and LUN number
