Check Power Requirements 3-5
Installation

Table 3-1 PDU Requirements
PDU part
number
PDU product
number Description Typical application Racking restrictions
E5929-63001 E5929A - Universal PDU
- Ten C-13 and one
C-19 outlets
- One C-20 inlet for
detachable cords
C-19 outlet is for newer
Hawk SPUs requiring a
20-amp connector.
C-20 inlet facilitates a
universal set of detachable
power cords.
Typically, for external UPS
applications
Must be racked on rails at or
above 4 EIAs to clear the
C-19 outlet.
If the C-19 outlet is not used,
must be racked on rails at or
above 1 EIA to clear the
C-20 inlet.
E5931A - N. America 220 V
PDU
- Ten C-13 outlets
- Attached 3 m power
cord with L6-30P
plug
Attached to a 3.0 or 5.5 kva
N. American UPS
None
E5932A - Europe 220 PDU
- Ten C-13 outlets
- Attached 3 m power
cord without plug
Attached to a 3.0 or 5.5 kva
European UPS
None
E4456-63001 E4456B - N. America 220 V
PDU
- Ten C-13 and one
C-19 outlets
- Attached power cord
with L6-20P plug
C-19 outlet is for newer
Hawk SPUs requiring a
20-amp connector.
Power cord typical for
N. America wall outlet
connection.
Must be racked on rails at or
above 4 EIAs to clear the
C-19 outlet.
If the C-19 outlet is not used,
must be racked on the
bottom of the rack without
rails.
E4457-63001 E4457B - Europe 220 V PDU
- Ten C-13 and one
C-19 outlets
- Attached power cord
without a plug
C-19 outlet is for newer
Hawk SPUs requiring a
20-amp connector.
Power cord has stripped
ends for attaching localized
plug.
Must be racked on rails at or
above 4 EIAs to clear the
C-19 outlet.
If the C-19 outlet is not used,
can be racked on the bottom
of the rack without rails.
C2786-63006 E4456A - N. America 220 V
PDU
- Ten C-13 outlets
- Attached power cord
with L6-20P plug
None
C2786-63007 E4457A - Europe 220 V PDU
- Ten C-13 outlets
- Attached power cord
without plug
Power cord has stripped
ends for attaching localized
plug.
None
