User Manual - A3661-90001

6-42 Unsolicited Event Log
0x666 Configured for Dual SP The disk array detected a change to a dual SP configuration.
0x667 Cache Recovering The SP is recovering the contents of the Write Cache
following a reboot.
0x668 Cache Recovered The SP successfully completed recovering the contents of the
Write Cache following a reboot.
0x66A Soft Vault Load Failure The SP could not load the saved contents of the Write Cache
from disk. However, there were no physical units with saved
data, so the Write Cache does not need to be loaded. This
situation can occur after SP memory is reconfigured, for
example, when both the RAID-3 memory size and the write
cache size are changed at the same time.
0x66B Front End Fibre Link Up The front-end Fibre Channel interface started running.
0x66C General Front End Fibre
Link Unsolicited
This event code is intended for use by development personnel
in the factory. Contact your Hewlett-Packard support
representative if this event code occurs.
0x66D Peer SP timed out The host SP has timed out waiting for the peer SP to reply to a
request.
0x670 Memory Dump This event code is intended for use by development personnel
in the factory. Contact your Hewlett-Packard support
representative if this event code occurs.
0x680 Invalid Data Sector Read The hardware found a bad checksum on a data sector.
0x681 Invalid Parity Sector
Read
The hardware found a bad checksum on a parity sector.
0x682 Invalid Sector Read The hardware found a bad checksum on a sector. There is not
enough information to determine whether the sector holds
data or parity information.
0x683 Data Sector
Reconstructed
The hardware reconstructed a data sector that had a
checksum or write stamp error.
0x684 Parity Sector
Reconstructed
The hardware reconstructed a parity sector that had a
checksum or write stamp error.
0x685 Hard Error The hardware detected an error other than a parity or write
stamp error.
0x686 Command Complete A command completed after a soft error was corrected.
0x687 Stripe Reconstructed Inconsistent write time stamps in a RAID group were
corrected.
0x688 Command Dropped An optional command was dropped.
Table 6-8 Informational Codes (Continued)
Event code Event code name Description
