Planning Considerations for Fibre Channel Topologies
81SAN High Availability Planning Guide
A multi-switch fabric is typically complex and provides the facilities to maintain
routing to all device N_Ports attached to the fabric, handle flow control, and
satisfy the requirements of the classes of Fibre Channel service that are supported.
Fabric Topology Limits
Operation of multiple directors or switches in a fabric topology is subject to the
following topology limits. Consider the impact of these limits when planning the
fabric.
■ Fabric Elements — Each fabric element is defined by a unique domain
identification (domain ID) that ranges between 1 and 31. A domain ID of 0 is
invalid. Therefore, the theoretical limit of interconnected directors or switches
supported in a single fabric is 31.
For additional information, refer to “Large Fabric Design Implications” on
page 109. For the latest supported topology limits, refer to
http://h18000.www1.hp.com/products/storageworks/san/documentation.html
or contact your local HP sales representative.
■ Heterogeneous fabric — Vendor interoperability in the fabric environment
is supported; therefore, fabric elements can include directors, edge switches,
and open-fabric compliant products supplied by original equipment
manufacturers (OEMs). To determine if interoperability is supported for a
product, or if communication restrictions apply, refer to the supporting
publications for the product or contact your HP representative.
■ Number of ISLs — The Director 2/64 supports 32 ISLs and the
Director 2/140 supports 70 ISLs. Edge Switches 2/12, 2/16, 2/24, and 2/32
support all ports. For redundancy, at least two ISLs should connect any pair of
director-class fabric elements. For information, contact your local HP sales
representative or refer to the following web site:
http://h18000.www1.hp.com/products/storageworks/san/documentation.html
.
■ Hop count — The Fibre Channel theoretical limit of ISL connections
traversed (hop count) in a single path through the fabric is seven. The
maximum hop count supported by a fabric is based on current design rules.
For information, refer to
http://h18000.www1.hp.com/products/storageworks/san/documentation.html
or contact your local HP sales representative.
