Configuration Planning Tasks
176 SAN High Availability Planning Guide
Table 5 lists operational setup tasks and includes the task owner, due date, and
comments.
Table 5: Operational Setup Tasks
Activity
Task
Owner
Due
Date
Comments
Obtain IP address and subnet
mask.
HAFM appliance (if installing on a
LAN with non-HP devices).
Directors and switches (if installing
on a LAN with non-HP devices).
Remote user workstation (optional).
Simple network management
protocol (SNMP) management
stations (optional).
Obtain gateway addresses for
router or other gateway devices
on company LAN.
To configure on HAFM appliance
and products (if installing on a LAN
with non-HP devices).
Assign host names. HAFM appliance and products
(optional).
Add host name to DNS
database.
HAFM appliance and products.
Determine what level of
HAFM
application user rights are to be
used for up to 16 users.
Determine if inband
management of the director or
switch is to be used and the type
(FICON or Open Systems).
HAFM appliance and
Fibre-Channel-attached server
peripheral (optional).
Determine if the call-home
feature is to be used.
Determine if the e-mail
notification feature is to be used.
Obtain e-mail addresses for event
notification and identify the e-mail
server.
