Physical Planning Considerations
170 SAN High Availability Planning Guide
Note: The Edge Switch 2/12 is not supported by the HAFM appliance.
In addition, the message Element Manager license key has not been installed -
Please follow up instructions to update permanent key is splashed across
views, indicating the Element Manager PFE key must be installed. The
Hardware View (Figure 63) for an Edge Switch 2/24 is shown as an example.
Figure 63: Hardware View (with Element Manager Message)
