About this Guide
12 SAN High Availability Planning Guide
Overview
This section covers the following topics:
■ Intended Audience
■ Related Documentation
Intended Audience
This book is intended for use by configuration and installation planners who are
experienced with the following:
■ System administration.
■ Customer engineering.
■ Project management.
Related Documentation
For a list of corresponding documentation, see the “Related Documents” section
of the Release Notes that came with the product.
For the latest information, documentation, and firmware releases, please visit the
HP StorageWorks web site:
http://h18006.www1.hp.com/storage/saninfrastructure.html
For information about Fibre Channel standards, visit the Fibre Channel Industry
Association web site, located at
http://www.fibrechannel.org
.
