HP Device Manager 4.6 - Deployment Guide

Port usage

Figure 2. Port usage in HPDM

Console

ServerMaster Repository

Gateway

Agent

TCP: 1099

TCP: 40001

TCP: 40003

TCP: 40002

TCP: 40003

TCP: 40005

TCP: 40012

Server/Agent

Gateway

Poll

UDP: 40000

PostgreSQL

TCP: 40006

TCP: 50000

PCoIP Zero Client

Agent

Server

Resource Monitor

TCP: 40009

Gateway Controller

TCP: 40008

Console/VNC Proxy

Agent/VNC Proxy

Reverse Shadow

TCP: 40004

Shadow

TCP: 40004

Note

This chart lists only the basic ports created by HPDM. For more information about common software port usage in HPDM,

see the HP Device Manager Administrator Guide.

Make sure that the ports are not blocked by a firewall or hijacked by other processes.

Deployment factors

This section lists the main factors that might influence HPDM deployment, and also gives some deployment

recommendations. The main factors are as follows:

• Hardware enviroment

• Network enviroment

• Number of devices

• HPDM logic
