HP Device Manager 4.6 - Database Schema Guide

dm_Ipscope
This is the IP scope table.
1. Table columns
Column name Type name Column size Nullable Primary key Description
alias nvarchar 50 NO √ Alias name
start_ip nvarchar 50 NO Starting IP address
stop_ip nvarchar 50 NO Ending IP address
2. Relevant UI
dm_network_alias
This is the network alias table.
1. Table columns
Column name Type name Column size Nullable Primary key Description
network nvarchar 50 NO √
alias nvarchar 50 NO
dm_os_types
This is the operating system type table.
1. Table columns
Column name Type name Column size Nullable Primary key Foreign key Description
os_type nvarchar 50 NO √ dm_rule.os_type Operating system type
2. Relevant information
This tables stores all activated operating system type information. Each record refers to an operating system tab on the
HPDM Console.
