HP Device Manager 4.6 - Database Schema Guide

Configuration-related tables
dm_conf
This is the configuration table.
1. Table columns
Column name Type name Column size Nullable Primary key Description
conf_option nvarchar 50 NO √ The configuration name
conf_value nvarchar 255 NO The configuration value
2. Relevant information
conf_option conf_value
AutoUpgradeAgent false
CancelTaskSwitch on
deviceSequence 1
EWFPolicy 2
ExcludeWorkTime 0-540-1020
folderId 1
FTPBatchAmount 5
FTPBatchinterval 2
FTPPort 21
FTPProtocol FTP
GatewayControlLevel 0
GeneralBatchAmount 0
GeneralBatchinterval 5
GeneralTimeout 30
hpdm.task.defer no
hpdm.task.wol no
LDAPBaseDN
LDAPDomain
LDAPEncrypt None
LDAPHost
LDAPPageSize 20
LDAPPort 389
LDAPRDNAttribute
LDAPSearchPass
LDAPSearchUser
LDAPServType AD
max 21
p1 location
p2 dept
p3 other
p4 other
p5 other
p6 other
Pollinginterval 30
