HP Device Manager 4.6 - Database Schema Guide

dm_keylog
This is the key log table.
1. Table columns
Column name Type name Column size Nullable Primary key Description
logdescription nvarchar 200 NO √
logevent smallint 5 NO √
logtime datetime 23 NO √
2. Relevant UI
dm_keyzero
This is the keyzero table.
1. Table columns
Column name Type name Column size Nullable Primary key Description
authkey nvarchar 250 NO √
create_date datetime 23 YES
expire_interval smallint 5 NO
import_date datetime 23 YES
This is an HPDM inner table. It is created when the database is installed, and the record values are fixed.
42
